ET_401

Lifting height : 0-1000cm
Safe load: 20KG
Fast speed: 30CM/s
Control model: DMX-512
Channel: 3CH
Connectors: 3 pin XLR connector in and out
Screen: 4 Digital tube display
Load-bearing cable diameter: Diameter 7.0MM
Synchronization error: Less 6MM
Adaptation voltage: AC90V-240V/50-60HZ
Standby power: 400W
IP Rating: IP20 Not waterproof
Environment temputure: - 10℃~50℃
Safety security: Physical braking, electronic protection
Installation: Vertical lifting
Motor Size: 606MM*350MM*305MM
Motor weight : 19.6 KG
Package: Carton or Fly case

DMX Signal Cable: 2*0.5M㎡*1.5M*1 pcs
Power Cable: 3*1.25M㎡*1.5M*1 pcs
Safety Cable: 3MM*600MM*1 pcs
Aluminum hook: Thick 30MM*Height 110MM* Width 82MM*2 pcs
Availability:

Lifting height
0-1000cm
Safe load
20KG
Fast speed
30CM/s
Control model
DMX-512
Channel
3CH
Connectors
3 pin XLR connector in and out
Screen
4 Digital tube display
Load-bearing cable diameter
Diameter 7.0MM
Synchronization error
Less 6MM


Adaptation voltage
AC90V-240V/50-60HZ
Standby power
400W


Environment temputure
- 10℃~50℃
Safety security
Physical braking, electronic protection
Installation
Vertical lifting
Motor Size
606MM*350MM*305MM
Motor weight
19.6 KG
Package
Carton or Fly case
DMX Signal Cable
2*0.5M㎡*1.5M*1 pcs
Power Cable
3*1.25M㎡*1.5M*1 pcs
Safety Cable
3MM*600MM*1 pcs
Aluminum hook
Thick 30MM*Height 110MM* Width 82MM*2 pcs
